Fiberglass Tape in Haridwar

Seal Joints with Fiberglass Tape

eadmin maMarch 24, 20266 min read
White Signature Fiberglass Tape sealing a hot steel pipe flange
In this article

High temperature fiberglass tape is the uncoated wrap you specify when a SIDCUL pipe flange or boiler joint needs sealing without a full cloth sheet.

You may be writing the indent for a manufacturing bay in Haridwar’s industrial estate, a power-plant outage window, or a metal-processing line that still runs hot after the night shift. The tape does not change with the pin code. Match the joint, the catalogue width, and the kilograms you need.

Seal the SIDCUL joint, not the line

Fitter wrapping Signature Fiberglass Tape on a boiler pipe joint

You are the person who has to name the material on the requisition. On a SIDCUL estate in Haridwar the job is often a flange, a valve neck, or a short boiler joint that needs a heat wrap and a seal, not a full cloth sheet cut for a whole duct run.

Signature Fiberglass Tape is white fiberglass tape with no coating. It is for high-temperature wrap and bind on pipes, cables, and equipment. It is not silicone insulation tape, and it is not a finished blanket.

Put it on the sealing jobs this tape is listed for.

  • Pipe and flange sealing: overlapping turns around a hot joint where cloth would waste width.
  • Boiler and furnace detail: short wraps beside a casing during an outage window.
  • Valve and expansion detail: a bind where the method calls for uncoated fiberglass tape.
  • Cable and equipment bind: heat-zone wraps named in the maintenance procedure.

Walk the joint before you raise the indent. Write the diameter, whether the wrap stays on after start-up, and whether the surface sits in the 550 °C to 900 °C window listed on these models. A manufacturing bay and a power-plant outage can share the same family and still need different widths.

If the drawing already calls for Signature Insulation Tape, stop. That is a different silicone product. Do not send uncoated fiberglass tape because the word “tape” matches. Do not invent silicone or vermiculite coatings on this SKU either — the adhesive coating field is no coating on every variant.

On the indent, write the job in plain words, such as “SIDCUL flange seal, stays on”. That line stops the wrong roll leaving stores.

Choose catalogue width for the flange

Signature Fiberglass Tape rolls of different widths on a stores rack

Thin city pages often say “multiple widths” and “customization available”. Stay on the catalogue. Signature Fiberglass Tape is a fixed list of width × thickness builds. Colour is white. Adhesive coating is none. Working temperature on every model is 550 °C to 900 °C — not a 500 °C to 700 °C window copied from an old sheet.

3 mm section builds:

  • DSZFTP3.25 — 25 × 3 mm
  • DSZFTP3.40 — 40 × 3 mm
  • DSZFTP3.50 — 50 × 3 mm
  • DSZFTP3.75 — 75 × 3 mm
  • DSZFTP3.100 — 100 × 3 mm

5 mm section builds: DSZFTP5.25, DSZFTP5.50, DSZFTP5.75, and DSZFTP5.100. Those coils are listed as 30 metre rolls. There is also DSZFTP7M50 at 50 mm × 50 m, 7 MIL thick, listed by the roll.

Measure the flange face. A narrow valve neck does not need a 100 mm wrap, and a wide joint should not be sealed with a 25 mm band that leaves bare metal. The product is not customizable. Do not invent a width between catalogue sizes.

Write the model number and the size on the indent. A line that only says “heat tape Haridwar” will be guessed in stores.

Plan kilograms for the outage list

Overlapping Signature Fiberglass Tape turns sealing a steel valve neck

You buy most of these models by the kilogram. Each DSZFTP3 and DSZFTP5 row carries an approximate metres-per-kilogram note so you can plan a SIDCUL outage list without guessing “two rolls” on the phone.

  • 3 mm examples: DSZFTP3.25 about 15 m per kg; DSZFTP3.50 about 7 m per kg; DSZFTP3.100 about 3 m per kg.
  • 5 mm examples: DSZFTP5.25 about 7 m per kg; DSZFTP5.50 about 4 m per kg; DSZFTP5.100 about 1.5 m per kg.
  • DSZFTP7M50 is listed at 460 gram per roll for the 50 mm × 50 m build.

Count the flanges and valve necks on the outage list. Multiply by the overlapping turns your method needs. Convert to kilograms using the model row, then add a spare for the next shift. A metal-processing bay that orders metres only will still run short when the unit on the catalogue is KG.

Watch the quote. If the line comes back as square metres, you are looking at cloth, not this tape. If a vendor adds silicone-coated or vermiculite-coated options under this product name, ask for the uncoated DSZFTP model instead.

If the unit on the indent is metres only and the model is a DSZFTP3 or DSZFTP5 row, change the line to kilograms against that model.

Overlap turns with no adhesive face

Stores clerk weighing Signature Fiberglass Tape coils before issue

This tape has no adhesive coating. A seal holds because you wrap overlapping turns the way the job method says, then fix the end as your site procedure already requires. Hand the fitter the model with the roll before the first flange on a night outage.

  • Step 1: Match the model on the roll to the indent before anyone starts wrapping.
  • Step 2: Start on clean metal. Oil and grit under the first turn stay under the seal.
  • Step 3: Pull each turn firm and even. Leave the overlap your method names. Do not stretch a short piece and hope the end holds.
  • Step 4: Secure the end the way the procedure already says. The tape is the barrier. It is not sticky tape from the tool crib.
  • Step 5: After the first heat cycle, walk the line. Look for a gap at a flange, a frayed edge, or a turn that has loosened.

Inspect the roll before issue. Retire tape that is soaked, burned, or unravelled to the core. Store dry, with the model written on the bin. A cool morning outside the estate does not mean the next boiler window can start with unmarked offcuts.

If a turn lifts after the first heat, rewrap with the listed fiberglass model. Do not cover the gap with adhesive tape from the stores drawer.

Made in Ahmedabad, sent to site

Cartons of Signature Fiberglass Tape ready for warehouse dispatch

Signature Fiberglass Tape is made by Darshan Safety Zone in Ahmedabad, under the Signature brand. The company has made fire safety and heat protection products since 2012, and its quality system is certified to ISO 9001:2015.

Orders can be dispatched across India, including to a site in Haridwar, and freight is confirmed in the quotation. There is no counter in Haridwar, and there is no same-day promise.

Discussion (0)

Join the conversation

Sign in to leave a comment for our applications team.

Sign in to comment
No comments yet. Be the first to ask a specification question.

What do buyers ask before specifying?

Common questions on materials, applications, and plant fit.

Is this tape silicone coated or vermiculite coated?
No. Every Signature Fiberglass Tape variant lists no coating. If a quote adds silicone or vermiculite under this product name, ask for the uncoated DSZFTP model instead.
What temperature should I write on the indent?
Every model lists 550 °C to 900 °C. Do not copy an older sheet that stops at 500 °C to 700 °C. Add the model number and the width × thickness size.
Can I order a custom width for an odd SIDCUL flange?
No. The product is not listed as customizable. Choose the nearest catalogue width and thickness, or ask for a recommendation against the joint you measured.
Why is the order in kilograms?
The DSZFTP3 and DSZFTP5 models are sold per kilogram, with approximate metres per kilogram on each row. DSZFTP7M50 is listed by the roll at 460 gram. Plan the seal from those figures.
Is Signature Insulation Tape the same product?
No. Insulation tape is a separate silicone product. Follow the name on the drawing before stores raises the indent.
Do you keep stock in Haridwar for same-day issue?
No. Manufacturing is in Ahmedabad. Signature products can be dispatched across India, and freight is confirmed in the quotation. There is no local warehouse promise.
Does the tape have an adhesive face for sealing?
No. The seal holds with overlapping turns and the end fix your site method already names. It is not sticky tape from the tool crib.
Can someone visit the plant to help pick the width?
Darshan Safety Zone can visit a site to recommend a product for the job. Ask for that when you request a quotation, and have the joint size and surface temperature ready. The visit does not replace the model number on the order.
