ceramic fiber tape

Wrap Joints with Ceramic Tape

eadmin maMarch 24, 20266 min read
White Signature Ceramic Fiber Tape wrapping a hot furnace pipe joint
In this article

Ceramic fiber tape is the high-temperature wrap you specify when a SIDCUL furnace joint or kiln flange outruns fiberglass tape.

You may be writing the indent for a boiler bay on Haridwar’s industrial estate, a foundry heat line, or a power-plant outage window that still runs hotter than E-glass tape can list. The tape does not change with the pin code. Match the joint, the DSZCTP model, and the kilograms you need.

Use ceramic when fiberglass is light

Fitter wrapping Signature Ceramic Fiber Tape on a kiln flange

You are the person who names the wrap on the requisition. On a SIDCUL estate in Haridwar, fiberglass tape often sits in the same stores rack. That tape lists a lower temperature window. When the furnace joint, kiln flange, or boiler detail sits in the ceramic range, write ceramic fiber tape — not a guess from the fiberglass bin.

Signature Ceramic Fiber Tape is white ceramic fiber tape sold by the kilogram under Ceramic Products. Working temperature on every model is 1260 °C to 1760 °C. It is not fiberglass tape, and it is not silicone insulation tape.

Put it on the jobs this tape is listed for.

  • Furnace and kiln wrap: joints and flanges beside extreme heat faces.
  • Boiler sealing detail: high-temperature gasket and wrap work during outages.
  • Foundry and steel heat zones: line wraps where ceramic tape is named on the method.
  • Cable and hose bundling: only when the drawing calls for ceramic fiber tape, not glass tape.

Walk the joint before you raise the indent. Ask for the surface temperature the wrap will see. If that number sits above the fiberglass window and inside 1260 °C to 1760 °C, stay on this product. Do not invent stainless reinforcement or “1000 °C+” marketing from an old sheet.

If the drawing already calls for Signature Fiberglass Tape, stop. That is a different FG Product line at 550 °C to 900 °C. Swapping ceramic in without the method does not fix a wrong indent, and swapping fiberglass onto a ceramic job leaves the wrap short.

On the indent, write the job in plain words, such as “SIDCUL kiln flange wrap, ceramic”. That line stops the wrong coil leaving stores.

Choose the layer for pour duty

Layered silver Signature Aluminized Apron fabric on a stores table

Thin city pages invent thickness in millimetres, a fixed kilogram weight, and a separate radiant figure up to 1200 °C. Stay on the model row. Signature Aluminized Apron is sold per piece (NOS) in four layer builds. Size is 24 × 36 inch on every row. Colour is silver. Coating is pure aluminium foil coated. Working temperature on every model is 600 °C to 800 °C.

  • DSZALAP2.0 — 2 Layer
  • DSZALAP3.0 — 3 Layer
  • DSZALAP4.0 — 4 Layer
  • DSZALAP5.0 — 5 Layer

Layer count is the variant axis. Weight is listed as as per actual — do not invent a 1.2 kg figure to fill a form. The product is not customizable. Do not invent a fifth size or a private thickness.

Ask the pour lead how long the worker stands at the hot face and how close they stand. A short inspection and a long pour shift are not the same duty, even on the same SIDCUL plot. Put the model number on the indent with the size and the temperature window.

If your site PPE procedure already names a layer count, copy that model. Do not drop a layer to make the apron feel lighter.

Pick width and thickness on DSZCTP

White Signature Ceramic Fiber Tape rolls of different widths on a table

Thin city pages say “multiple widths” and “custom sizes available”. Stay on the catalogue. Signature Ceramic Fiber Tape uses DSZCTP models — not old DSZCFTP codes. Colour is white. Coils are 30 m per roll. Working temperature on every row is 1260 °C to 1760 °C.

3 mm section builds include:

  • DSZCTP3.25 — 25 × 3 mm
  • DSZCTP3.38 — 38 × 3 mm
  • DSZCTP3.40 — 40 × 3 mm
  • DSZCTP3.50 — 50 × 3 mm
  • DSZCTP3.75 — 75 × 3 mm
  • DSZCTP3.100 — 100 × 3 mm

5 mm section builds include DSZCTP5.25, DSZCTP5.38, DSZCTP5.40, DSZCTP5.50, and DSZCTP5.100. There is no 75 mm width on the 5 mm section. The product is not customizable. Do not invent a width between catalogue sizes, and do not invent SS metallic or non-metallic reinforcement that is not on the model row.

Measure the flange or joint. A narrow valve neck does not need a 100 mm wrap, and a wide kiln face should not be covered by a 25 mm band that leaves bare metal.

Write the DSZCTP model number and the size on the indent. A line that only says “ceramic tape Haridwar” will be guessed in stores.

Wrap, secure, then inspect the coil

Stores clerk checking a Signature Ceramic Fiber Tape coil before issue

Hand the fitter the model with the coil before the first kiln flange on a night outage. Secure the wrap the way your site method already says.

  • Step 1: Match the model on the coil to the indent before anyone starts wrapping.
  • Step 2: Start on clean metal. Dust and grit under the first turn stay under the wrap.
  • Step 3: Pull each turn firm and even. Leave the overlap your method names. Do not stretch a short piece and hope the end holds.
  • Step 4: Secure the end the way the procedure already says. The tape is the barrier. It is not sticky tape from the tool crib.
  • Step 5: After the first heat cycle, walk the line. Look for a gap at a flange, a frayed edge, or a turn that has loosened.

Inspect the coil before issue. Retire tape that is soaked, burned, or unravelled to the core. Store dry, with the model written on the bin. A cool morning outside the estate does not mean the next furnace window can start with unmarked offcuts.

If a turn lifts after the first heat, rewrap with the listed ceramic model. Do not cover the gap with fiberglass tape from the lower-temperature bin.

Made in Ahmedabad, sent to site

Cartons of Signature Ceramic Fiber Tape ready for warehouse dispatch

Signature Ceramic Fiber Tape is made by Darshan Safety Zone in Ahmedabad, under the Signature brand. The company has made fire safety and heat protection products since 2012, and its quality system is certified to ISO 9001:2015.

Orders can be dispatched across India, including to a site in Haridwar, and freight is confirmed in the quotation. There is no counter in Haridwar, and there is no same-day promise.

Discussion (0)

Join the conversation

Sign in to leave a comment for our applications team.

Sign in to comment
No comments yet. Be the first to ask a specification question.

What do buyers ask before specifying?

Common questions on materials, applications, and plant fit.

Is Signature Ceramic Fiber Tape the same as Signature Fiberglass Tape?
No. Ceramic fiber tape lists 1260 °C to 1760 °C under Ceramic Products. Fiberglass tape is a separate FG Product line at 550 °C to 900 °C. Follow the name and temperature on the method.
What temperature should I write on the indent?
Every DSZCTP model lists 1260 °C to 1760 °C. Do not copy an older sheet that only says 1000 °C or above. Add the model number and the width × thickness size.
Does this tape have stainless steel reinforcement?
No stainless or non-metallic reinforcement is listed on the current model rows. Do not invent that claim from stale HTML.
Can I order a custom width for an odd SIDCUL flange?
No. The product is not listed as customizable. Choose the nearest catalogue width and thickness, or ask for a recommendation against the joint you measured.
Why is the order in kilograms?
The tape is sold per kilogram, with approximate metres per kilogram on each model row and 30 m coils. Plan the wrap from those figures.
Do you keep stock in Haridwar for same-day issue?
No. Manufacturing is in Ahmedabad. Signature products can be dispatched across India, and freight is confirmed in the quotation. There is no local warehouse promise.
My old drawing still says DSZCFTP. What do I order?
Use the current DSZCTP model that matches the width and thickness you need. Ask for that code on the quotation instead of the old CFTP label.
Can someone visit the plant to help pick the model?
Darshan Safety Zone can visit a site to recommend a product for the job. Ask for that when you request a quotation, and have the joint size and surface temperature ready. The visit does not replace the model number on the order.
